    Arduino 3 LED Blinking Project

    1. Place three LEDs on the breadboard.
    2. Connect each LED through a 220Ω resistor.
    3. Connect LED 1 to pin 8.
    4. Connect LED 2 to pin 9.
    5. Connect LED 3 to pin 10.
    6. Connect all grounds to Arduino GND.
    7. Upload the code using Arduino IDE.
    8. The LEDs should blink one after another.
